The IP Wall Mount Speaker (SW15-ABS / SW15P-ABS) from Composite Solution is a compact yet powerful solution for public address and emergency communication systems. Built to deliver high-definition sound with a 15W output (also available in 10W and 25W variants), it ensures loud and clear audio across wide areas.
This speaker supports advanced protocols such as SIP, ONVIF, and HTTP API, allowing easy integration with VoIP devices, VMS platforms, and other communication systems. It is designed for modern infrastructures that require two-way communication, scheduled announcements, and real-time alert notifications.
Available in two versions—SW15-ABS (adapter-powered) and SW15P-ABS (PoE-powered)—it offers flexible installation options. The rugged IP55-rated ABS enclosure ensures durability and reliable performance in both indoor and outdoor environments.
With features like event-triggered alerts, pre-recorded message playback, and the advanced 48K OPUS codec, this speaker delivers crystal-clear, low-latency audio, making it ideal for schools, factories, transport hubs, and commercial facilities.
Key Features:
🔊 Audio Performance
- 10W / 15W / 25W Output Options – Powerful and clear sound for wide coverage
- 48K OPUS Codec – High-definition, low-latency audio quality
- Pre-Recorded Playback – Supports scheduled and emergency announcements
- Event-Triggered Alerts – Real-time notifications via alarm input
🔗 Integration & Compatibility
- Supports SIP, ONVIF, and HTTP API
- Compatible with VoIP devices and ONVIF VMS
- Enables two-way communication
⚡ Power & Installation
- SW15-ABS – Adapter-powered version
- SW15P-ABS – PoE-powered version
- Easy wall-mount installation
- Flexible deployment for various environments
🛡️ Design & Durability
- IP55 Weatherproof Rating – Suitable for indoor & outdoor use
- Strong and lightweight ABS material
- Compact and rugged design for long-term use
Specifications:
| Feature | Details |
|---|---|
| Product Name | IP Wall Mount Speaker |
| Brand | Composite Solution |
| Variants | 10W / 15W / 25W |
| Model | SW15-ABS / SW15P-ABS |
| Max SIP Account | 2 |
| Function | Two-way communication, pre-recorded messages, schedule play, GPIO in, HTTP control |
| Protocols | SIP, ONVIF, HTTP, IPv4, DHCP, RTSP, RTP, RTCP, TCP, UDP, ARP, FTP, TFTP, NFS, NTP |
| Network Interface | RJ45 (10BASE-T / 100BASE-TX) |
| Codec | OPUS 48 kHz, MP3 44.1 kHz, G.722, G.711 PCMU/PCMA |
| DTMF | In-band, RFC2833, SIP INFO |
| Power Supply | DC 12V/24V or PoE |
| Material | ABS |
| Color | White & Black |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -20°C to 85°C |
| Dimensions | 167 × 142 × 232 mm |
| Weight | 870g |
| Protection | IP55 Rated |
Applications:
- Schools & Educational Institutions
- Factories & Industrial Areas
- Transport & Railway Stations
- Commercial Buildings
- Public Address & Emergency Systems
